Model: FIB-100B
| Subject | Unit | Technical parameter | |
|---|---|---|---|
| Power supply | Voltage/Phase/Frequency | 380V/3P/50Hz | |
| Refrigerant | R22 or R404A | ||
| Capacity | Kg/day | 10000 | |
| Temperature | Ambient temperature | ℃ | 35 |
| Waterinlet temperature | ℃ | 20 | |
| Operating power | Total running power | Kw | 40.69 |
| Installment power | Kw | 50 | |
| Operating power of cold water pump | Kw | 2.2 | |
| Compressor | Manufacturer | Bitzer | |
| Refrigeration capacity | Kw | 86.6 | |
| Operating power | Kw | 35.98 | |
| Compressor COP/EER | Kw/kw | 2.41 | |
| Horse power | Hp | 25×2 | |
| Condenser | power | Kw | 3.3 |
| Cooling way | Water cooling | ||
| Working time | Ice making time | h | 7.5 |
| Ice doffing time | h | 0.5 | |
| Dimension | Weight of each block | Kg/block | 50 |
| Size of block ice | (L×W×H)(mm) | 480×160×700 | |
| Size of cooling tower | (L×W×H)(mm) | Ф2000×2410mm | |
| Size of water feeding pipe | 1-1/4" | ||
| Operating weight of cooling tower | Kg | 670 | |
| Water supply pressure requirement | Bar | 1 | |
